Large-scale DNA sequencing of a variety of organisms has led to a detailed annotation of genes and regulatory elements dispersed throughout their genomes.  These genetic elements are embedded in the DNA fibers packaged in the nucleus.  Such genome packaging is not simply accomplished by condensing genetic material, but distant genomic loci are also non-randomly localized in the nucleus.

More specifically, we have been studying the roles of the condensin and cohesin complexes in 3D genome organization in the fission yeast, mouse and human systems.  To pursue these studies, we employ Hi-C and ChIA-PET genomic technologies and single locus/live-cell imaging approach.  Our ongoing studies demonstrate that the condensin and cohesin complexes are key molecular machines that organize the functional 3D genome structures.  Excitingly, our study points out that condensin plays an important role in cellular senescence, a major tumor suppression mechanism.  By combining the fission yeast, mouse, and human systems with the latest genomic, genetic, cell biological, and biochemical approaches, we seek to determine how condensin and cohesin organize the functional 3D genome structures and participate in various biological processes, including transcriptional regulation and chromosomal dynamics, and how they contribute to oncogenic processes.

Deciphering 3D genome structure


[In the figure: Modeled 3D structure of the fission yeast genome.]

We have modeled the 3D genome structure of the model organism fission yeast using a genomic approach that combines the molecular biology procedure called chromosome conformation capture (3C) and next-generation DNA sequencing.  To accurately model this genome structure, we successfully fused microscopy and genomic data (Tanizawa et al. Nucleic Acids Research 2010).

Bridging Transcription and 3D Genome

We have identified a molecular mechanism whereby the dividing cell protects and faithfully segregates actively transcribed genes.  Specifically, we have shown that the condensin subunit Cnd2 binds directly to the most important general transcription factor, the TATA box-binding protein TBP, and that TBP recruits condensin molecules onto RNA polymerase III-transcribed genes and highly active Pol II-transcribed genes (many ribosomal protein genes) through the Cnd2-TBP interaction (Figure A).  Condensin in turn tethers these highly active genes to centromeres, such that they are protected and faithfully segregated during mitosis.  We found that the interaction between two classic factors, condensin and TBP, plays a pivotal role in 3D chromosome organization, and ensures that a critical set of genes, the actively transcribed housekeeping genes, are accurately segregated during mitosis (Figure B and C).  This mechanism coordinates transcription with chromosomal architecture by linking dispersed gene loci with centromeres.  This study was published in Molecular Cell (Iwasaki et al. 2015).


[In the figure: (A) The interaction between the condensin complex and TBP mediates clustering of Pol III-transcribed genes (tRNA) and highly active Pol II-transcribed genes at centromeres.  (B) In wild-type cells, those highly active genes are tethered to centromeres, and chromatin loops derived from centromeres are supercoiled.  This chromosomal arrangement efficiently transmits mechanical force pulling the kinetochore to chromosomal arm regions, thereby improving the fidelity of chromosomal segregation.  (C) In condensin mutant, highly active genes do not associate with centromeres.  Therefore, physical force at the kinetochore is diffused and inefficiently transmitted to chromosomal arm regions, resulting in chromosomal segregation defects in condensin mutant.]

Actions of Condensin and Cohesin in 3D Genome Organizations

How condensin and cohesin govern the 3D structure of the eukaryotic genome is an exciting research area.  Using an important genomic methodology, referred to as ChIA-PET (Chromatin Interaction Analysis by Paired-End Tag sequencing), we have been able to capture condensin- and cohesin-mediated gene contacts throughout the fission yeast genome.  Our results have revealed that although condensin and cohesin bind to the same gene loci, they direct different association networks (Figure).  Cohesin mediates local contacts, i.e. between loci positioned within 100 kb (red), whereas condensin drives longer-range contacts (blue).  Cohesin forms small topological chromatin domains of approximately 100 kb, while condensin organizes 300 kb – 1 Mb domains.  These studies demonstrate that the two important protein complexes, condensin and cohesin, are both essential for the assembly of the functional genome architecture, but their roles in the 3D genome organization (gene contacts and topological domain organization) are significantly different.  This study has been published in Nature Genetics (Kim et al. 2016).


[In the figure: ChIA-PET genomic analyses successfully mapped condensin (left) and cohesin (right)-mediated gene contacts throughout the fission yeast genome.  Blue and red lines represent gene contacts between two gene loci positioned more than and less than 100 kb away, respectively.]

Visualizing associations between discrete genomic regions in live cells

We have employed a live-cell imaging system to visualize the genomic region carrying lacO repeats.  We have integrated lacO repeats into the genomic region of interest and introduced LacI-GFP proteins by genetic crosses.  We have been able to visualize several diverse genomic regions: centromeres, telomeres, ribosomal DNA (rDNA) repeat locus, and loci carrying retrotransposons or Pol III-transcribed genes including tRNA and 5S rRNA, in live fission yeast cells.  Using a laser scanning confocal microscope, we have examined positions of the genomic loci in the 3D nuclear compartment at as short as 1.5-second intervals.  Importantly, these studies to elucidate gene contacts in the 3D nuclei of live cells have demonstrated that condensin-mediated contacts between centromeres and the genomic loci carrying Pol III-transcribed genes or retrotransposons are highly dynamic.  Furthermore, our results have revealed that centromeric motion, which is controlled by cytoplasmic microtubules, contributes to the mobility of non-centromeric gene loci.  We propose that centromeres serve as “Genome Flexibility Elements” by connecting dispersed gene loci to highly mobile centromeres (Kim et al. Journal of Cell Science 2013).


 [In the figure: A model for the role of centromeric motion in the mobility of many gene loci during interphase.  Microtubule polymerization in cytoplasm actively pushes centromeres in nucleoplasm.  Centromeres associate with dispersed gene loci, and these gene contacts are mediated by condensin.  Centromeres and their associating chromosomal loci migrate in a coordinated fashion.]

3D Genomic Basis of Cellular Senescence

Cellular senescence is defined as a state of stable cell growth arrest, and it is our intrinsic defense against abnormal cell proliferation associated with every type of cancer.  The process of senescence requires global alterations in the genome architecture and radical changes in gene expression.  We have shown that the human condensin complex functions in global 3D genome reorganization during the important process of cellular senescence (Yokoyama et al. Cell Cycle 2015).


 [In the figure: Condensin triggers cellular senescence and its associated genome organization.  Condensin expression in non-senescent human cell (left) induces senescence and completely transforms global genome architecture (right), which is referred to as Senescence-Associated Heterochromatic Foci (SAHF).  DNA was visualized by DAPI.]
